3 — Silixon-HCB

Hybrid Circuit Board

What It Is

Silixon-HCB is Hardin Labs' hybrid circuit board technology — a substrate that merges conventional copper-trace electronics with embedded Silixon ceramic thermal management channels, galinstan liquid-metal interconnects, and photonic signal waveguides into a single monolithic laminate. The result is a board that simultaneously carries digital signals at conventional copper speeds in the passive regions, photonic signals at light speed through embedded silica-SiOC waveguide layers, and thermal energy out of hot zones through the galinstan micro-channel network — all without the use of separate heat sinks, optical fiber connectors, or external cooling systems.

Architecture

The HCB is built as a 16-to-32 layer laminate. Odd-numbered layers carry standard copper signal traces and power planes. Even-numbered layers alternate between galinstan-filled thermal channels (sealed in borosilicate micro-tubes to prevent gallium oxidation) and Silixon ceramic dielectric films that provide both electrical isolation and structural rigidity. Every fourth layer pair includes a photonic routing layer: a thin SiOC waveguide film with embedded diffraction gratings that redirect laser pulses from vertical-cavity surface-emitting laser (VCSEL) emitters to photodetector arrays across the board. This photonic layer eliminates the electromagnetic interference that burdens traditional high-density copper routing in the GHz-to-THz frequency range.

Thermal Performance

Galinstan's thermal conductivity of approximately 16 W/m·K and its liquid-phase flow characteristics allow the HCB's embedded channels to extract heat from processor die sites at a rate exceeding 500 W/cm², a figure that no solid-state thermal interface material can match. The channels connect to micro-pump nodes at the board edge, circulating galinstan through external radiators during heavy compute loads. Under idle conditions, natural thermosiphon action within the sealed loops is sufficient to manage background dissipation without pumping power.

Applications

Silixon-HCB is the primary interconnect substrate used inside the Silixon Cube compute architecture, the Silixon-GPU, the SIP processor, and the GNDS storage array. It is also specified for the DART aircraft's avionics bay, where the combination of extreme shock tolerance, radiation hardness from the ceramic matrix, and passive cooling reduces the avionics bay's total size and mass by an estimated 60% versus a conventional PCB-plus-heat-sink solution.
